4.3“ inch TFT LCD Display 480x272 TN TFT LCD Display

Model No.: ZX430TFT06A

This display module ZX430TFT06A is a transmissive type color active matrix TFT(Thin Film Transistor) liquid crystal display(LCD) without a capacitance touchscreen .This module is composed of a TFT LCD module, a backlight unit. The resolution of a 4.3-inch contains 480(RGB)*272 dots and can display up to 16.7M colors.

inquiry

Description

	Feature	Spec
Characteristics	Size	4.3 inch
	Resolution	480*272
	Interface	RGB
	Connect type	Connector
	Color Depth	16.7M
	Technology Type	a-Si TFT
	Display Spec. Pixel pitch(mm)	0.198*0.198
	Pixel Configuration	R.G.B. Vertical Stripe
	Display mode	Normally white, Transmissive
	Driver IC	ST7282
	Contrast Ratio	300
	Luminance	-
Machanical	Gray Viewing Direction	10 O'clock
	LCM (MM)	105.567.23
	Active Area (mm)	95.04*53.856
	With/without TSP	without
	Weight(g)	TBD
	LED numbers	7 LEDS
