| Manufacturer | IVO |
| Model Name | M080AWAA R3 |
| Screen Size | 8 inch |
| Pixel Number | 1280(RGB)*720 , WVGA |
| Active Area(mm) | 176.64 × 99.36 (H×V) |
| Outline(mm） | 187.20 × 117.05 × 8.4 (H×V×D) |
| Pixel Pitch(mm) | 0.138 × 0.138 (H×V) |
| Pixel Arrangement | R.G.B Vertical Stripe |
| Luminance | 750 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | all |
| Response time | 20 (Typ.)(Tr/Td) ms |
| Display Mode | Normally black |
| Color Depth | 16.7M , 70% NTSC |
| Backlight | WLED, 30K hours, without Driver |
| Net Weight | TBD |
| Touchscreen | without |
| Signal Type/interface Type | Parallel RGB (1 ch, 8-bit) , 40 pins , FPC |
| Voltage Supply | +3.3 V |
| Max. Ratings | Storage Temp.: -40 ~ +95 (°C) Operating Temp.: -30 ~ +85 (°C) |
| Package | IVO Original package; 40 pcs/ctn |
